DS400 — High-Performance Wireless Sensor for Variable-Speed Machines
$689.00
/ ea
Min. order 10 unitsIn stock · ships worldwide
3-yr batteryCE & FCCIP69
Details & specifications
Built for the hard cases — variable-speed, variable-load and intermittent machines.
The DS400 is DHMSCare's high-performance wireless sensor, with an extended 0–8000 Hz range and a wide ±60 g dynamic range to capture high-energy and high-frequency faults that standard sensors miss. Onboard edge AI computes RPM and start/stop, ideal for VFD-driven and continuously varying machinery.
Key Specifications
| Vibration sensor | MEMS, 3-axis |
| Frequency response | 0–8000 Hz (±3 dB) |
| Acceleration range | ±60 g |
| Sampling | 16 kHz, up to 32,768 points |
| Edge AI | RPM calculation + start/stop detection |
| Sampling interval | Configurable 5 / 10 / 20 / 30 / 60 min |
| Temperature | −40 to 120 °C, ±1.0 °C |
| Wireless range | 50 m (dense plant) / 300 m (line-of-sight) |
| Battery | Replaceable A-size Li-ion, ~3-year life |
| Dimensions / weight | 38 × 38 × 75.5 mm / 140 g |
| Ingress protection | IP69 |
| Certification | CE, FCC |
Built for the DHMSCare AI platform — pair with the DG310 gateway.
